WFQ700-1300 Series Horizontal Computer Slitting Machine






 WFQ700-1300 Series Horizontal Computer Slitting Machine



1)Functions and Characteristics:
This machine is suitable for slitting and rewinding such various roll materials as BOPP,PET,CPP,PVC, aluminum foil and roll paper.,etc. and can cut edge,separate and cut material according to different requirements during production.
2)  Performance and Characteristics:
1. Main Motor: Vector motor with inverter controller.
2. Independent master control panel, more flexible and easier operation.
3. Automatic EPC for unwinding, photocell is suitable for tracking the edge  and the printed line of material.
4. Equipped with air shaft for unwinding material loading,magnetic powder brake for unwinding tension control.
5. Air shaft for rewinding, Magnetic powder clutch for rewinding tension control
6. Equipped with air trim discharge conveying system.
7. Automatic meter counting device.
8. Pressure roller for rewinding to make rewinding roll more uniform.

 slittingmachineslitplasticfilm







slitting machine



 Main Technical Variables:

Tyep

LWF-900

LWF-1100

LWF-1300

LWF-1500

LWF-2000

Max.Width of Material

900mm

1100mm

1300mm

1500mm

2000mm

Max.material Diameter

Φ700mm

Φ700mm

Φ700mm

Φ700mm

Φ700mm

Max. Rewinding diameter

Φ500mm

Φ500mm

Φ500mm

Φ500mm

Φ500mm

Width of Final Roll (mm)

50-800

50-1000

50-1200

50-1400

50-1900

Max.Slitting Speed(m/min)

160m/min

160m/min

160 m/min

160m/min

160m/min
